TR-H2L1 2.8

Book A Demo How To Buy

Technical Specifications

WDR:

DWDR 105 dB

Maximum video output resolution:

1920x1080

Image sensor:

1/2.9" CMOS

Power supply:

12V DC

Lens (mm):

2.8

Net Weight (kg):

0.15

Sensitivity(Lux):

0,1

Dimensions (mm):

30×33×30

Power consumption, Watt:

8.4

Working temperature, C°:

–10 °C… +50 °C

Day/Night Mode:

Electronic IR-filter

Overview

TRASSIR TR-H2L1 (2.8 mm)

This 2 MP (1920 × 1080) analog camera integrated in a micro enclosure, the largest side of which measures 32 mm. Compatible with AHD, HD-CVI, HD-TVI data transfer formats: transmits an uncompressed 2 MP video signal via coaxial cable over a distance of up to 500 m (1,000 ft).

Resolution by format:

- AHD — 2 MP.
- HD-CVI — 2 MP.
- HD-TVI — 2 MP.
- PAL — 960H

Functionality:

- DWDR is a software-based image processing solution designed to enhance the visibility of shaded objects.
- 2D DNR: Noise reduction.
- Day/night mode with an electronic IR cut-off filter that blocks infrared rays.
- Broadcast speed: 25 frames per second.

Specifications:

TR-H2L1 (2.8 mm) is built on a 1/2.9" progressive scan CMOS matrix with 0.01 lux sensitivity. Equipped with a 2.8 mm fixed focal length lens. Power supply: 12 V DC. Current consumption: 300 mA. Size: 30 × 33 × 30 mm Working temperature: –10 °C... +50 °C.

Documentation

TR-H2L1 passport (eng).pdf
