TR-D8121IR2 v6 2.8
Audio:
ArrayWDR:
RWDR 120 dBResolution:
2MPForm factor:
SphereWi-Fi:
-Maximum video output resolution:
1920x1080Image sensor:
1/2.7" CMOSBitrate (Mb/sec):
8Power supply:
DC 12 V, PoELens (mm):
2.8Net Weight (kg):
0.38Sensitivity(Lux):
0,005Ingress protection:
IP66Dimensions (mm):
Ø92.8x92.2Power consumption, Watt:
6.3Working temperature, C°:
-40…+60Day/Night Mode:
Mechanic IR-filterNetwork interfaces:
RJ-45
TRASSIR TR-D8121IR2 v6 (2.8 mm)
2 MP (1920 × 1080) IP-camera is designed taking into account the conditions of round-the-clock year-round outdoor operation in places out of sight of security personnel: the metal case is protected from mechanical impacts according to the IK10 code, from moisture and dust - according to the IP66 standard, operating temperatures from –40 ° C… +60 ° C, lightning protection - TVS 4000 V, range of integrated backlighting - 25 m.
Functionality:
- - Built-in microphone.
- - Detection of people.
- - Motion detection.
- - Area control (detection of intrusion / exit from the zone).
- - Detection of crossing the virtual line.
- - WDR 120 dB - minimizes the effect of changes in light level on image quality.
- - 3D DNR - spatial noise reduction.
- - Supports vertical resolution (corridor mode) with an aspect ratio of 9:16.
- - Defog - Automatically removes blur introduced by fog or smoke by enhancing the contrast.
- - BLC - Backlight Compensation.
- - Day / night mode with ICR, with sufficient illumination to block the rays of the infrared range to normalize color reproduction; in the dark, the filter is shifted away from the matrix so that its sensitivity increases and the backlight can work.
- - Compression with H.265 +, H.264 +, H.265, H.264 codecs.
- - Broadcast speed - 25 fps.
Basics:
TR-D8121IR2 v6 (2.8 mm) is equipped with a 2.8 mm fixed focal length lens, 82 ° horizontal field of view, 44 ° vertical field, F / 1.8 aperture. Equipped with an RJ-45 network port, a microSD slot with a capacity of up to 128 GB, a power connector. Power Supply - 12V DC or PoE. The maximum power consumption is 6.3 W. Dimensions - Ø92.8 × 92.2 mm. Weight - 380 g.
