Technical Specifications

Audio:

Array

WDR:

RWDR 120 dB

Frame rate:

IR range:

35m

Resolution:

2MP

Form factor:

Bullet

Wi-Fi:

Yes

Maximum video output resolution:

1920x1080

Image sensor:

1/2.7" CMOS

Bitrate (Mb/sec):

Power supply:

12V DC

Lens (mm):

2.8

Net Weight (kg):

0.460

Sensitivity(Lux):

0,005

Ingress protection:

IP67

IR:

Yes

Case material:

Metal

Dimensions (mm):

183.3×67.3×63.9

Power consumption, Watt:

3.9

Working temperature, C°:

-40°C ... +60°C

Day/Night Mode:

Mechanic IR-filter

Video compression:

H.264, H.265, H.264+, H.265+

Overview

TRASSIR TR-D2121IR3W v3 (2.8 mm)

The 2MP (1920 × 1080) IP-camera is adapted for round-the-clock year-round outdoor operation: the case is protected from dust and moisture according to the IP67 standard, operating temperatures from –40 ° C ... +60 ° C, the range of the integrated IR illumination is 35 m.

The camera supports motion detection recording and day / night mode with a mechanical IR cut filter that refracts IR rays in sufficient lighting; in the dark, the filter is shifted away from the matrix to increase its sensitivity and backlight operation.

Functionality:

- Detection of people.
- Motion detection software.
- Detection of crossing the virtual line and control of the area (detector of intrusion / exit from the zone).
- Built-in microphone.
- WDR 120 dB - reducing the influence of changes in the level of illumination on the image quality: double scanning with different shutter speeds and the subsequent formation of the final balanced frame.
- 3D DNR - spatial noise reduction.
- BLC - backlight correction.
- Defog - elimination of imperfections introduced by fog or smoke.
- Compression of H.264 and H.265, H.264 + and H.265 +.
- Broadcast speed - 25 fps. Bitrate - 8 Mbps.

Basics:

TR-D2121IR3W v3 (2.8 mm) is based on a high-sensitivity (0.005 lux) CMOS sensor 1 / 2.7 inches, equipped with a 2.8 mm fixed focal length lens, F / 1.8 aperture, horizontal field of view 100 °, vertical field - 54 °. Equipped with an RJ-45 network port. Power supply - DC 12 V. Power consumption - 3.9 W max. Dimensions - 183.3 × 67.3 × 63.9 mm, weight - 460 g.

Documentation

TR-D2121IR3Wv3 passport (eng).pdf
