TR-D6225IR20 v3 4.6–152
PoE:
4Audio:
ArrayWDR:
WDR (140 dB)Audio in/out:
1/1, RCAFrame rate:
25IR range:
up to 200 mDigital noise Reduction:
2DNR / 3DNRResolution:
2MPForm factor:
PTZ speed domeMaximum video output resolution:
1920x1080Image sensor:
1/2.8" CMOS STARVIS 2MPBitrate (Mb/sec):
up to 16MbpsPower supply:
PoE (802.3at) / 12V DCLens (mm):
4.6-152 mm, F1.6-F4.3Net Weight (kg):
5300 / 7800Sensitivity(Lux):
0.001Lux (F1.6)Local storage:
MicroSD до 512GbCase material:
AluminumDimensions (mm):
222 х 372Power consumption, Watt:
PoE: 24W (IR on), DC: 24W (IR on)Working temperature, C°:
-30°C ... +70°C (IR on)Video compression:
Н.265 / H.264B / MJPEGKey features
• Wide dynamic range (Real WDR 140dB)
• IR range up to 200 meters
• Built-in video archive (Edge Storage) – local recording on MicroSD card* up to 512GB*
• IVS: Human detection; Line crossing; Intrusion detection / Abandoned / Missing objects detection; Autotracking; Motor vehicle / Non-motor vehicle detection
• Two-way audio channel (1 in / 1 out)
• Alarm IN/OUT (1/1)
• TCP/IP, ICMP, HTTP, HTTPS, FTP, DHCP, DNS, DDNS, RTSP, PPPoE, NTP, UPnP, SMTP, QoS, IPV4, MULTICAST, RTMP, ONVIF protocols
• IP66 weather-tight case
• Power supply 12V DC or PoE
___________________________
* MicroSD card is not included into camera package
